| SPECIFICATIONS 技术参数 |
| Full Scale Output 灵敏度输出 | 1.5±10%mV/V | Recommended Excitation 使用电压 | 10V(15V Maximnm) |
| Zerc Balance 零点输出 | ±0.02mV/V | Reference Max.Platform Size | Capacity<1Kg:200*200mm |
| Nonlinearity 非线性 | <±0.017% | 大秤台尺寸 | Capacity<1Kg:230*230mm |
| Repeatability 重复性 | <±0.017% | Insulation Resistance 缘阻抗 | >2[50V DC]GΩ |
| Hysteresis Error 滞后 | <±0.017% | Nominal Temperature Range 工作温度 | -10℃to40℃/14℉to104℉ |
| Creep in 30 min 30分钟蠕变 | <±0.023% | Safe Overload 安全过载 | 150% of full scale |
| Input Resistance 输入电阻 | 405Ω±15 | Breaking Overload 极限过载 | 300% of full scale |
| Outnput Resistance 输出电阻 | 350Ω±5 | IP Rating 防护等级 | IP66 |
| Element Materia 材质 | Aluminum 铝合金 | Cable Color Code 颜色码 | Exc(输入)+:Red(红);Exc(输入)
-Black(黑);Sig(输出)+Green(绿);
Sig(输出)-:Whit白 Shield Bare(屏蔽) |
|
